1964-88 C10 Transmission Crossmember

SKU: XFGM-11201 Category:

X-Factor Lightweight Aluminum CrossMember for 1964-88 Chevy C-10 trucks, compatible with all common manual and automatic transmission models.

$329.00

In Stock

If you don't know what you need, call our technical sales staff at 931-646-4836

Description

Made from powder coated T-6061 aluminum and provides a strong, lightweight support for a long list of transmissions, and provides clearance for up to 3.5? exhaust. Requires drilling of frame to secure side plates.

The X-Factor for 1964-88 Chevy 10’s is adjustable to fit the TREMEC TKO, T56 and Magnum, LGT700, Muncie, T-10, Saginaw and Richmond manual transmissions along with automatics ranging from the Powerglide and Turbo350 to the Turbo400, 700r4 and 4l60(e). It is compatible with common GM isolator mounts.

Each cross member comes with the modular aluminum center section, sliding steel frame mounting plates and installation hardware and is tested to withstand over 1000ft-lbs of twist. The lightweight construction means big weight savings over steel, plus it looks cool.

Weight: 14.0000 lbs

Dimensions: W8.0000" x H8.0000" x L32.0000"
